| Product characteristics |
| Number of inputs and outputs |
Number of digital outputs: 2; Number of analogue outputs: 1 |
| Measuring range |
|
| Process connection |
threaded connection Rc 2 internal thread DN50 |
| Application |
| Special feature |
Gold-plated contacts |
| Application |
totaliser function; empty pipe detection; for industrial applications |
| Media |
conductive liquids; water; hydrous media |
| Note on media |
| conductivity: ≥ 20 µS/cm |
| viscosity: < 70 mm²/s (40 °C) |
|
| Medium temperature [°C] |
-10…70 |
| Pressure rating [bar] |
16 |
| Pressure rating [Mpa] |
1.6 |
| Electrical data |
| Operating voltage [V] |
18…32 DC; (according to EN 50178 SELV/PELV) |
| Current consumption [mA] |
< 150 |
| Protection class |
III |
| Reverse polarity protection |
yes |
| Power-on delay time [s] |
5 |
| Inputs / outputs |
| Number of inputs and outputs |
Number of digital outputs: 2; Number of analogue outputs: 1 |
| Inputs |
| Inputs |
counter reset |
| Outputs |
| Total number of outputs |
2 |
| Output signal |
switching signal; analogue signal; pulse signal; frequency signal; IO-Link; (configurable) |
| Electrical design |
PNP/NPN |
| Number of digital outputs |
2 |
| Output function |
normally open / normally closed; (parameterisable) |
| Max. voltage drop switching output DC [V] |
2 |
| Permanent current rating of switching output DC [mA] |
250; (per output) |
| Number of analogue outputs |
1 |
| Analogue current output [mA] |
4…20; (scalable) |
| Max. load [Ω] |
500 |
| Analogue voltage output [V] |
0…10; (scalable) |
| Min. load resistance [Ω] |
2000 |
| Pulse output |
flow rate meter |
| Short-circuit protection |
yes |
| Type of short-circuit protection |
pulsed |
| Overload protection |
yes |
| Frequency of the output [Hz] |
0.1…10000 |
| Measuring/setting range |
| Measuring range |
|
| Display range |
| -720…720 l/min |
-43.2…43.2 m³/h |
|
| Resolution |
|
| Set point SP |
|
| Reset point rP |
| 5…597 l/min |
0.3…35.8 m³/h |
|
| Analogue start point ASP |
|
| Analogue end point AEP |
| 120…600 l/min |
7.2…36 m³/h |
|
| Low flow cut-off LFC |
|
| In steps of |
|
| Measuring dynamics |
1:120 |
| Volumetric flow quantity monitoring |
| Pulse value |
0.0001…600 x 10³ m³ |
| In steps of |
0.0001 m³ |
| Pulse length [s] |
0,008…2 |
| Temperature monitoring |
| Measuring range [°C] |
-20…80 |
| Display range [°C] |
-40…100 |
| Resolution [°C] |
0.2 |
| Set point SP [°C] |
-19.2…80 |
| Reset point rP [°C] |
-19.6…79.6 |
| Analogue start point [°C] |
-20…60 |
| Analogue end point [°C] |
0…80 |
| In steps of [°C] |
0.2 |
| Accuracy / deviations |
| Flow monitoring |
| Accuracy (in the measuring range) |
± (0,8 % MW + 0,5 % MEW) |
| Repeatability |
± 0,2% MEW |
| Temperature monitoring |
| Temperature drift |
± 0,0333 °C / K |
| Accuracy [K] |
± 1 (bei 25 °C, Q > 15 l/min) |
| Response times |
| Flow monitoring |
| Response time [s] |
0.35; (dAP = 0) |
| Delay time programmable dS, dr [s] |
0…50 |
| Damping for the switching output dAP [s] |
0…5 |
| Temperature monitoring |
| Dynamic response T05 / T09 [s] |
T09 = 3 (Q > 15 l/min) |
| Software / programming |
| Parameter setting options |
Flow monitoring; quantity meter; Preset counter; Temperature monitoring; hysteresis / window; normally open / normally closed; switching logic; current/voltage/frequency/pulse output; start-up delay; display can be deactivated; Display unit; empty pipe detection |
| Interfaces |
| Communication interface |
IO-Link |
| Transmission type |
COM2 (38,4 kBaud) |
| IO-Link revision |
1.1 |
| SDCI standard |
IEC 61131-9 CDV |
| Profiles |
Smart Sensor: Process Data Variable; Device Identification |
| SIO mode |
yes |
| Required master port type |
A |
| Process data analogue |
3 |
| Process data binary |
2 |
| Min. process cycle time [ms] |
5 |
| Supported DeviceIDs |
| Type of operation |
DeviceID |
| Default |
389 |
|
| Operating conditions |
| Ambient temperature [°C] |
-10…60 |
| Storage temperature [°C] |
-25…80 |
| Protection |
IP 65; IP 67 |
| Mechanical data |
| Weight [g] |
2747.5 |
| Materials |
stainless steel (1.4404 / 316L); stainless steel (1.4571/316Ti ); PEI; FKM; PBT-GF20; TPE-U |
| Materials (wetted parts) |
stainless steel (1.4404 / 316L); stainless steel (1.4571/316Ti ); PEEK; FKM |
| Process connection |
threaded connection Rc 2 internal thread DN50 |
| Displays / operating elements |
| Display |
| Display unit |
6 x LED, green (l/min, m³/h, l, m³, 10³, °C) |
| switching status |
2 x LED, yellow
