| Model | FD-XS20 | |||
| Supported pipe materials | Metal pipes, Plastic pipes (soft/hard) *1 | |||
| Supported fluids | Liquids (water, oil, adhesive, grease, chemical solutions, etc.) *1 | |||
| Supported fluid temperature | 0 °C (no freezing on the pipe surface) to 100 °C 32 to 212 °F (Pipe surface temperature) | |||
| Clamp set model | Plastic pipe/tube attachment | FD-XC20R1, FD-XC20R2, FD-XC20R3, FD-XC20R4 | ||
| Metal pipe attachment | FD-XC20M1, FD-XC20M2*2 | |||
| Maximum rated flow rate | Outer diameter of pipe 3/8 ” (9.53 mm) , ø 10 0.39 “, ø 10.5 0.41 “: 0 to 15.00 L/minOuter diameter of pipe ø 12 0.47 “, 1/2 ” (12.7 mm) , ø 13.8 0.54 “: 0 to 20.00 L/min | |||
| Zero cut flow rate | 0.10 L/min (standard), 40 mL/min (high resolution*3)*4 (variable, default) | |||
| Display resolution | Instantaneous flow rate | 0.001/0.01/0.1 L/min (standard), 0.1/1/10 mL/min (high resolution*3) (Displayed on controller) | ||
| Shot amount | 0.001/0.01/0.1 L (standard), 0.001/0.01/0.1/1 mL (high resolution*3) (Displayed on controller) | |||
| Repeatability | Plastic pipe/tube attachment | Response time: 50 ms | F.S. | ± 0.1 %*5*6 |
| Instantaneous flow rate | Outer diameter of pipe 3/8 ” (9.53 mm) , ø 10 0.39 “: ±15 mL/minOuter diameter of pipe ø 12 0.47 “, 1/2 ” (12.7 mm): ±20 mL/min*5*6 | |||
| Response time: 500 ms | Outer diameter of pipe 3/8 ” (9.53 mm) , ø 10 0.39 “: ±4.7 mL/minOuter diameter of pipe ø 12 0.47 “, 1/2 ” (12.7 mm): ±6.3 mL/min*5 | |||
| Metal pipe attachment | Response time: 50 ms | F.S. | ±0.15 %*5*6 | |
| Instantaneous flow rate | Outer diameter of pipe 3/8 ” (9.53 mm) , ø 10 0.39 “, ø 10.5 0.41 “: ±23 mL/minOuter diameter of pipe ø 12 0.47 “, 1/2 ” (12.7 mm) , ø 13.8 0.54 “: ±30 mL/min*5*6 | |||
| Response time: 500 ms | Outer diameter of pipe 3/8 ” (9.53 mm) , ø 10 0.39 “, ø 10.5 0.41 “: ±7.2 mL/minOuter diameter of pipe ø 12 0.47 “, 1/2 ” (12.7 mm) , ø 13.8 0.54 “: ±9.5 mL/min*5 | |||
| Hysteresis | Variable | |||
| Integrated unit display | 0.01/0.1/1/10/100 L (standard), 0.1/1/10/100/1000/10000 mL (high resolution*3) (displayed on controller) | |||
| Display method | Status indicator | |||
| Environmental resistance | Enclosure rating | IP65/IP67 (IEC60529) , IP68G (JIS C0920) *7 | ||
| Ambient temperature | -10 to 60 °C (No freezing) 14 to 140 °F | |||
| Relative humidity | 35 % to 85 %RH (No condensation) | |||
| Vibration resistance | 10 to 55 Hz, double amplitude 1.5 mm 0.06 “, 2 hours each for X,Y,Z direction | |||
| Shock resistance | 50 G 11 ms 3 times each for X,Y,Z direction | |||
| Material | Sensor head | Head body: PPS/PPSU, in-cable amplifier: PPS, cable: PVC, controller connector: PPS/PBT/POM | ||
| Clamp set | For plastic pipe | Body, fixing screw: PPS, detection surface: special rubber, pipe support rubber: FKM, sensor head fixing screw: SUSXM7 | ||
| For metal pipe | Metal: SUS304/SUSXM7, detection surface: special rubber, clamp support rubber: FKM, sensor head fixing screw: SUSXM7 | |||
| Weight | Approx. 260 g | |||
Cảm biến lưu lượng Keyence FD-XS20
Danh mục sản phẩm
-
Cảm biến lưu lượng Keyence FD-XS20
- Lượt xem: 698
- Cảm biến lưu lượng Keyence FD-XS20
